一種新穎的SAR真實場景原始數據頻域模擬方法
A Novel Method of SAR Real Scenario Raw Data Frequency-domain Simulation
-
摘要: 采用時域模擬方法來實現真實場景數據模擬時，由于計算機計算速度和數據容量的限制，數據模擬十分困難。該文提出了一種新穎的SAR真實場景原始數據的頻域模擬方法。該方法改變了傳統的時域到頻域?qū)?yīng)關系，采用空域到頻域的對應關系，真實場景數據兩維FFT后在頻域插值和移位，并與所采用的頻域轉移函數相乘，再經過IFFT得到模擬的原始數據。通過對點目標模擬和真實場景數據模擬仿真試驗，證明了該方法的有效性，模擬結果顯示該模擬方法與以往的模擬算法相比極大地提高了模擬速度。
-
關鍵詞:
- SAR; 真實場景; 原始數據模擬
Abstract: Because of the limitation of the PCs velocity and capability, it is difficult to simulate SAR real scenarios in time-domain. In this paper, a novel method of SAR real scenario raw data simulation, frequency-domain simulation, is introduced. This method employs space-frequency relationship, other than the traditional time-frequency relationship. After 2D FFT, the scenarios data are interpolated and shifted. Then these data are multiplied by the transfer function of frequency-domain, and followed by IFFT. The simulated raw data can be obtained. The validity of this method is fully manifested by the simulation experiments of point target and the real scenarios. The result show that the method in this paper, compared with the time-domain methods, greatly improve the simulation speed. -
Small D, Meier E, Nuesch D. Efficient geolocation and image simulation for extended SAR strip maps. IGARSS 2001. Geoscience and Remote Sensing Symposium Proceedings. Sydney, NSW Australia, 2001, vol.7: 3152-3154.[2]Franceschetti G, Iodice A, Migliaccio M, Riccio D. Simulation of SAR interferometric raw signal pairs corresponding to real scenes. IGARSS'98. Geoscience and Remote Sensing Symposium Proceedings. Seattle, WA USA,1998, vol.5: 2653 -2655.[3]Desai A S, Wilkinson A J, Inggs M R. GPR SAR simulation and image reconstruction. IGARSS 2001. Geoscience and Remote Sensing Symposium Proceedings. Sydney, NSW Australia, 2001, vol.7: 2076-2078.[4]岳海霞, 楊汝良. 星載合成孔徑雷達模擬源研究. 遙感技術與應用, 2004, 19(4): 253-257.[5]平慶偉, 劉洲峰, 何佩琨. 一種快速SAR真實場景模擬方法.現代雷達, 2003, 6(6): 29-31.[6]Franceschetti G, Schirinzi G. A SAR processor based on two- dimensional FFT codes[J].IEEE. Trans. Aerosp. Electron. Syst.1990, 26(2):356-366 -
