利用2-D射影變換實現多視圖下元素的預報
PREDICTING IMAGE ELEMENTS USING 2-D PROTECTIVE TRANSFORMATION FROM MULTIPLE VIEWS
-
摘要: 在描述多視圖的幾何元素對應關系方面,2-D射影變換是一種有力工具。該文把求解2-D射影變換矩陣的方法從單純的四點對應擴展到多種組合形式的四元素對應當中,如:4點、4線、3點1線、3線1點和2點2線等。基于2-D射影對應所描述的視圖關系,可以有效解決雙視圖和三視圖條件下的點元素或線元素的預報問題。由于沒有任何估計因素的介入,提高了預報結果的準確性。靈活組合點線多種元素建立視圖關系使得預報環境適應面廣泛。實驗結果驗證了方法的有效性。Abstract: 2-D projective collineation provides an ideal mathematical tool for describing planar element correspondence in multiple views. This paper extends the solution methods for 2-D projective transformation matrix from 4 points corresponding to variety combinations of points and lines corresponding, such as 4 points, 4 lines, 1 point and 3 lines, 3 lines and 1 point, and 2 points and 2 lines, etc. Based on the relationship between two views indicated as 2-D projective collineation, prediction problems about points or lines from two views or three views can be solved effectively. Without any estimating parameters involved, the prediction results accuracy is improved. Freely combining points and lines on describing relationship between views makes the application field wider. The methods proposed here have been verified by experimental results.
-
O.D. Faugeras, L. Robert, What can two images tell us about a third one?, International Journalof Computer Vision, 1996, 18(3), 5-19.[2]Zhengyou Zhang, Determining the epipolar geometry and its Uncertainty, A Review, InternationalJournal of Computer Vision, 1998, 27(2), 161-195.[3]E.B. Barrett et al., Linear resection, intersection, and perspective-independent model matchingin photogrammetry: Theory, SPIE, Vol 1567, 1991, Applications of Digital Image ProcessingXIV, 142-169.[4]龍澤斌編著,幾何變換,湖南科學技術出版社,1984年第一版,第三章.[5]L. Quan, Invariants of six points and projective reconstruction from three uncalibrated images,IEEE Trans. on Pattern Analysis and Machine Intelligence, 1995, 17(1), 34-46. -
