全通多相網絡濾波器組的理論和設計
THEORY AND DESIGN OF UNIFORM FILTER BANKS USING ALL-PASS FILTERS
-
摘要: 本文進一步研究了應用全通濾波器實現均勻N帶濾波器組的設計理論。我們提出了一種兩級全通型濾波器組的結構,第一級為周期性鏡像半帶濾波器,第二級為兩個N/2帶的帶通濾波器組。第一級的阻帶恰好可以抑制第二級的不可控帶,實現了全通型多相濾波器的連續阻帶持性。并且給出了綜合濾波器組的實現方案,可以使整個分析/綜合系統完全消除混疊和幅度失真。最后本文給出了一個實例。
-
關鍵詞:
- 全通濾波器; 濾波器組; 正交鏡像濾波器
Abstract: The theory of uniform filter banks using all-pass filters is further developed. A filter-bank structure using two-stage all-pass filters is proposed. The pre-stage is half-band filters with period, the post-stage is two pass-band filter banks. The stopband of the pre-ttage filter just controls the don t-care band of the poststage filter using all-pass polyphase, so that a realization of continuous stopband property is obtained Moreover, a method of implementing synthesis filter banks is given, which eliminates aliasing and amplitude distortions of analysis/synthesis system. Finally, an example is listed. -
R. E. Crochiere, L. R. Rabiner, Multirate Digital Signal Processiag, Englewood Cliff, NJ: Prentice-Hall, (1983).[2]M.Vetterli, Signal Processing, 10 (1986) 3, 219-244.[3]P. P. Vaidyanathan, Proc. IEEE, 78 (1990) 1,56-93.[4]M. Vetterli, D. Le Gall, IEEE Trans. on ASSP, ASSP-37(1989) 7, 1057-1071.[5]P. P. Vaidyanathan, IEEE Trans. on CAS, CAS-33 (1986) 11, 1045-1064.[6]T. Q. Nguyen, P. P. Vaidyanathan; IEEE Trans. on ASSP, ASSP-36 (1988) 5,693-705.[7]K. Swatninathan, P. P. Vaidyanathan, IEEE Trans. on CAS, CAS-33 (1986) 12, 1170-1191.[8]P. A. Regalia, S. K. Mitra, P. P. Vaidyanathan, Proc. IEEE, 76(1988) 1,19-37.[9]M. Renfor, T. Saramaki, IEEE Trans. on CAS, CAS-34(1987) 1,24-39.[10]孫少凡,QMF濾波器和16kb/s子帶編碼的研究,北京郵電學院電信工程系碩士論文,北京,1990年. -
