摘要:
VVMOS晶體管是一種開有V形槽的垂直溝道高頻功率MOS場效應器件,它的一個主要優點是與其它MOS器件一樣不會發生二次擊穿,然而近來一些作者報道MOS器件有負阻擊穿效應,而這種負阻擊穿效應也會引起二次擊穿,導致器件燒毀。我們?cè)跍y(cè)量自制的VVMOS晶體管時,也觀察到了負阻擊穿,經過研究,提出了縱向寄生npn雙極晶體管的VVMOS晶體管負阻擊穿模型,在此基礎上還提出了幾種抑制負阻擊穿效應的方法,在采用了這些方法后,負阻擊穿效應被減弱,甚至被消除,從而證實了所提出的VVMOS晶體管負阻擊穿模型。
Abstract:
VVMOS transistor is a new type of high frequency power MOS transistor with vertical channels at the surface of the V-groove. Like other MOSFET s, one of the important features is no secondary breakdown, However, these is negative resistance breakdown, effect in MOSFET's is reported recently by some authors. The reported effects may eause secondary breakdown, and result in destructive damage to the de-vices.While measuring the VVMOSFET s made in our laboratory, we have also observed the destructive negative resistance breakdown effect. And model based on the effect of parasitic vertical bipolar npn transistor is proposed to explain this effect. Some using these method, the negative resistance breakdown effect has been lowered of even eliminated, and thus the proposed negative resistance breakdown model for VVMOSFET's is verified.
