基于PC機的斷層圖象序列3-D表面重建
PC-BASED 3-D RECONSTRUCTION FROM CROSS-SECTIONAL IMAGES
-
摘要: 由斷層圖象序列重建三維物體模型及其可見表面顯示是目前國際上十分活躍的研究課題。本文對X射線CT圖象序列重建三維對象模型,以及可見表面3-D顯示進行了研究。提出一種給定分段點數的輪廓多邊形近似方法,繼而提出一種快速斷面圖象間輪廊插值方法。對重建出的人體肝臟體元陣列,用深度和梯度明暗顯示方法進行顯示,肝臟可見表面的3-D顯示結果令人滿意。全部軟件都是在以PC/AT為主機,配以PC-VISION圖象處理板的微機圖象處理系統上,用C語言編程實現的。
-
關鍵詞:
- 三維重建; 斷層圖象; 三維顯示
Abstract: It is an active researching area to reconstruct the model of 3-dimensional object from cross-sectional images and to display its visible surfaces. In this paper, the theory and the method of reconstructing the model of 3-D object and displaving its visible surface from X-CT imaqes are studied. Giving the number of segment points, a polygonal approximation method is presented. Then a fast contour interpolating method is introduced. The reconstructed liver voxel set is displayed with the depth-only shading method and the depth gradient shading method, the result is satisfactory. The software is written in C language and runs on PC-VISION image processing system. -
E. Kepple, IBM, J. Res. Develop., 29(1975), 2-11.[2]H. Fuch, Z. M. Kedem, S. P. Uselton, Communications of the ACM, 20(1977)10, 693-70.[3]H. N. Christiansen, T. W. Sederberg, Computer Graphics, 12(1978)3, 187-192.[4]A. Sunguruff, D. Greenberg, Computer Graphics, 12(1978)3, 196-202.[5]G. T. Herman, H. K. Liu, Computer Graphics and Image Processing, 9(1979)1, 1-21.[6]D. J. Meagher, Efficient Synthetic Image Generation of Arbitrary 3-D Objects, Proc. of the IEEE Computer Society Conf. on Pattern Recognition and Image Processing, 1982, Las Vegas, NV, pp. 473-478.[7]W. E. Lorensen, H. E. Cline, Computer Graphics, 21(1987)4, 16.3-169.[8][8][9]Wei-Chung Liu et al., IEEE Trans, on MI, MI-7(19138)3, 225-232.[10]Gideon Frieder, Dan Gordon, R. Authory Reynolds. IEEE Computer Graphics and Application, 5(1985)1, 52-60.[11]Dan Gordon, R. A. Reynolds, Computer Vision, Graphics and Image Processing, 29(1985)3, 361-376. -
