平面波在三維完全匹配層中的傳播特性
PROPAGATION CHARACTERS OF PLANE WAVE IN THE PERFECTLY MATCHED LAYER
-
摘要: 完全匹配層(PML)良好的吸波特性已成功地用于FDTD問題。Katz給出了三維問題分量場所滿足的12個微分方程,但未對波在PML中的傳播特性進行討論。本文基于Katz的微分方程組,推導出了平面波解、波數及其阻抗。
-
關鍵詞:
- 完全匹配層; 吸收邊界條件; 時域有限差分; 截?cái)嗝?/a>
Abstract: The Perfectly Matched Layer(PML)is very effective in absorbing propagating wave, so that it has been successfully applied in FDTD research. Katz(1994) derived 12 differential equations in three-dimensional PML, but there is no conclusion for the propagation characters of plane wave in PML such as wave expression ,wave number and wave impedance. These characters are investigated in this paper. -
Lindman E L. wee-space boundary conditions for the time dependent wave equation. J.Comput.[2]Phys., 1975,18(1): 66-78.[3]Engquist B, Majda A. Absorbing boundary conditions for the numerical simulation of waves[J].Math.Comp.1977, 31(139):629-651[4][3][5]Berenger J P. Perfectly matched layer for the absorption of electromagnetic wave[J].J. Comput. Phys.1994, 114(2):185-220[6]Katz D S, et al. Validation and extension to three dimension of the Berenger PML absorbing boundary condition for FD-TD meshes. IEEE Microwave and Guided Wave Lett., 1994, 4(8):[7]8-270.[8]Andrew W V, et al. IEEE Microwave and Guided Wave Lett., 1995, 5(6): 192-194.[9]Moor T G, et al. Theory and application of radiation boundary operators. IEEE Trans. on AP, 1988, AP-36(12): 1797-1812.[10]Mur G. Absorbing boundary conditions for the finite-difference approximation of the time-domain electromagnetic field equations. IEEE Trans. on EMC, 1981, EMC-23(4): 377-382. -
