雙向負阻晶體管張弛振蕩器分頻鎖相特性的研究
FRACTIONAL PHASE-LOCKING OF A RELAXATION OSCILLATOR BY PERIODICALLY APPLIED IMPULSES
-
摘要: 本文用簡單模型描述了雙向負阻晶體管(BNRT)張弛振蕩器在周期沖激作用下的分頻鎖相特性。對于任何分?jǐn)?shù)p/q,給出了在參數空間中分頻鎖相區的普遍的分析表達式。對于BNRT張弛振蕩器進行了分頻鎖相實驗,實驗結果與計算相符,說明理論分析是正確有效的。
-
關鍵詞:
- 張弛振蕩器; 雙向負阻晶體管; 分頻鎖相
Abstract: A simple model is used to describle the fractional phase-locking of a relaxation oscillator by periodically applied impulses. For any definite fraction p/q, analytic expressions are derived for the phase-locking region in the parameter space. Experimental results for a bidirectional negative resistance transistor (BNRT) relaxation oscillator agree with the computed ones. -
李鳳銀,周旋等,半導體學報,5(1985)6,685-687.[2]朱照宣,余道衡,科學通報,32(1987)1,22-24.[3]Tracy Allen, IEEE Trans. on CAS, CAS-30(1983)9, 627-632.[4]余道衡,朱照宣,電子科學學刊,9(1987)2,176-180. -
