雙極型電路通用綜合方法與電路三要素理論
Universal synthesis of bipolar circuits and theory of three essential circuit elements
-
摘要: 該文在電路三要素(信號,網絡和負載)理論的基礎上提出雙極型電路通用綜合方法。文中首先引入適用于電壓型和電流型電路的廣義二值信號,推導出源信號和負載簡化定理。由此分析各單元電路結構和推導出相應的元件級電路表達式,進一步找出一種新的電路實現方式。在此基礎上設計出新的低壓TTL和多射型ECL元件級電路。最后經過電路實驗證明理論的正確性。
-
關鍵詞:
- 電路三要素理論; 雙極型電路綜合方法; 廣義二值信號; 低壓TTL和多射型ECL電路
Abstract: On the basis of theory of three essential circuits elements, this paper presents a universal synthesis of bipolar circuits. The generalized binary signal to be applicable to voltagemode and current-mode circuits is introduced first. Then the simplified theorem on origin signal and load is proved, which is used for anlayzing the structure of any unit circuits, for deducing the relevant expression in component stage and for finding out a new manner to realize TTL and ECL circuits. In accordance with the above theory a new low voltage TTL circuit and multimeitter ECL circuit in component stage are found out. The above theory is proved to be correct through experiments on circuits. -
李翰蓀,電路分析基礎,上冊,人民教育出版社,1978,3,70-85.[2]方振賢,劉瑩,電路三要素理論和布爾代數失效原因分析,電子科學學刊,1999,21(6),806-813.[3]閻石,數字電子技術基礎,北京,高等教育出版社,1981,9,54-230.[4]吳訓威,杭國強,基于比較運算與多晶體管的開關電路,中國科學(E輯),1997,27(5),444-452.[5]吳訓威,基于電壓-電流的電路綜合方法,電子科學學刊,1999,21(3),384-390. -
