一般二維數字系統的低噪聲優化實現
OPTIMAL STATE-SPACE REALIZATIONS OF GENERAL 2-D DIGITAL SYSTEMS WITH LOW ROUNDOFF NOISE
-
摘要: 本文給出了一般二維數字系統的兩種高效率狀態空間結構;導出了這兩種結構的能控性和能觀性格拉姆矩陣的有關性質;建立了二維數字系統定點運算的全局噪聲模型;據此獲得了一般二維數字系統低噪聲、高效率的優化實現,文中舉例說明了本文的兩種結構的噪聲性能和計算效率各不相同。Abstract: Two computationally efficient state-space structures for general 2-D digital systems described by Roesser s local state-space model are presented. Some properties of controllability and observability Gramians of the above two structures are derived. The overall roundoff noise model of 2-D digital systems implemented with fixed-point arithmetic is given. On the basis of the above theory, the low roundoff noise optimal state-space realizations of general 2-D digital systems are obtained. Finally, an example is given to demonstrate the differences of round- off noise arid computational efficiency between the above two structures.
-
B. G. Mertzios, IEEE Trans. on CAS, CAS-32(1985)2, 201-204.[2]W. S. Lu et al., IEEE Trans. on CAS. CAS-32(1985)10, 1080-1081.[3]T. Lin et al., IEEE Trans. on CAS, CAS-33(1986)7, 724-730.[4]W. S. Lu et al., IEEE Trans. on CAS, CAS-33(1986)10, 965-973.[5]S. J. Varoufakis et al., IEEE Trans. on CAS, CAS-34(1987)3, 289-292.[6]G. E. Antoniou et al., IEEE Trans. on CAS, CAS-35(1988)8, 1055-1058.[7]S. Y. Kung et al., Proc. IEEE, 65(1977)6, 945-961.[8]張宏科等, 電子學報, 18 (1990) 6, 107-109.[9]A. Kawakami, IEEE Trans. on CAS, CAS-37(1990)3, 425-432.[10]T. Hinamoto et al., IEEE Trans. on CAS, CAS-35(1988)5, 609-610.[11]T. Lin et al., IEEE Trans. on CAS, CAS-35(1988)5, 610-611.[12]W. S. Lu et a1., IEEE Trans. on CAS, CAS-35(1988)5, 611-612.[13]M. Kawamata et al., Minimization of sensitivity of 2-D state-space digital filters and its realization to 2-D balanced realizations, Proc. 1987 IEEE on ISCAS, Philadelphia, PA, May[14]87, pp. 710-713.[15]肖承山等, 二階數字簿波器的近最佳實現,全國NN-SP會議論文集,南京,1991年,第287-290頁.[16]肖承山, 伏態空間數字濾波器高效率低噪聲的優化實現, 信號處理, 將發表在1993年第3期上. -
