基于Inagaki模式方法分析導體內諧振特性

張云峰; 姜成貴; 曹偉

基于Inagaki模式方法分析導體內諧振特性

計量
- 文章訪問數: 2588
- HTML全文瀏覽量: 125
- PDF下載量: 703
- 被引次數: 0
出版歷程
- 收稿日期: 2005-02-28
- 修回日期: 2005-07-25
- 刊出日期: 2006-09-19

Inagaki Mode Approach to Electromagnetic Scattering of Conducting Bodies at Interior Resonances

摘要

摘要: 當應用電場積分方程或磁場積分方程對導體散射特性進行矩量法分析時，在某些離散的頻率點即內諧振點上，常常出現解的不穩定或不唯一情況。為了解決這一問題，該文提出了一種新型的消除內諧振的方法。這種方法基于電場積分方程，利用Inagaki模性質有效地去除了諧振模式，獲得內諧振條件下正確的導體散射特性。該方法具有概念清晰和計算簡便等優點。計算結果與公開發表的文獻結果以及解析解相比，一致性良好。
- 電磁散射;矩量法;Inagaki模;電場積分方程;磁場積分方程;內諧振
Abstract: When either electric field integral equation or magnetic field integral equation is employed to analyze electromagnetic scattering of conducting bodies, at some discrete resonance frequencies, the solution of Method Of Moments(MOM) matrix will be nonunique or unstable. In this paper, a new effective method is presented to solve this problem. At the interior resonance frequencies, Inagaki mode method, based on electric field integral equation, is used to filter out resonance modes and obtain right parameters. The proposed method possesses the merits of clarity in concept and simplicity in computation. A good agreement is achieved between the calculated results and the published as well as the analytical results.

HTML全文

參考文獻(1)

Harrington R F. Field computation by moment methods. New York: Macmillan, 1968: 49-72.[2]Harrington R F. Time harmonic electromagnetic field. New York: McGraw-Hill, 1961: 37-94.[3]Rao S M, Wilton D R, Glisson A W. Electromagnetic scattering by surfaces of arbitrary shape[J].IEEE Trans. on Antennas Propagation.1982, 30(5):409-418[4]Berg P M, Korkmaz E, Aubakar A. A constrained conjugate gradient method for solving the magnetic field boundary integral equation[J].IEEE Trans. on Antennas Propagation.2003, 51(6):1168-1176[5]Mautz J R, Harrington R F. H-field, E-field and combined-field solutions for conducting bodies of revolution. A.E.U., 1978, 32(4): 157-164.[6]Mautz J R, Harrington R F. A combined-source solution for radiation and scattering from a perfectly conducting body[J].IEEE Trans. on Antennas Propagation.1979, 27(4):445-454[7]Yaghjian A D. Augmented electric and magnetic field equations[J].Radio Science.1981, 16(6):987-1001[8]Sarkar T K, Rao S M. A simple technique for solving E-field integral equations for conducting bodies at internal resonances[J].IEEE Trans. on Antennas Propagation.1982, 30(6):1250-1254[9]Klein C A, Mittra R. An application of the condition number concept to the solution of scattering problems in the presence of interior resonant frequencies. IEEE Succinct Papers, 1975:431-435.[10]Canning F X. Singular value decomposition of integral equations of EM and applications to the cavity resonance problem[J].IEEE Trans. on Antennas Propagation.1989, 37(9):1156-1163[11]Canning F X. Protecting EFIE-based scattering computationsfrom effects of interior resonances[J].IEEE Trans. on Antennas Propagation.1991, 39(11):1545-1552[12]曹偉, 陳勁松. 內諧振條件下導體散射特性的雙正交模法分析. 電波科學學報，1995, 10(1): 16-22.[13]Inagaki N. Eigenfunctions of Hermitian iterated operator and its application to numerical analysis. Proc. International Symposium on Antennas Propagation, Japan, 1978, (7): 295-298.[14]Inagaki N, Garbacz R J. Eigenfunctions of composite Hermitian operator with application to discrete and continuous radiating systems[J].IEEE Trans. on Antennas Propagation.1982, 30(7):571-575[15]Cao Wei. A unified MoM-based modal formulation with application to EM problems. [PhD. Dissertation], Nagoya Institute of Technology, Japan, 2001.[16]孫玉發，徐善駕. 一種求解目標內諧振時散射截面的有效方法. 電波科學學報，2001，16(1): 76-79.[17]孫玉發，徐善駕. 基于奇異值分解的方法求解目標內諧振時的散射截面. 電子學報，2001，29(7): 958-960.
