微波吸收材料電磁參數的計算機輔助測量
COMPUTER AIDED MEASUREMENT OF THE ELECTRO- MAGNETIC PARAMETERS FOR THE MICROWACE ABSORBING MATERIALS
-
摘要: 微波吸收材料的電磁參數在評價吸收劑性能時是一個重要指標。參數重建屬于電磁逆散射問題,而傳統的阻抗方法僅利用正好足夠的測試數據來獲取電磁參數,未能利用冗余數據對材料的電磁性能作綜合評定。本文介紹結合網絡參數的多點測量阻抗的優化方法,在測量線上實現了電磁參數的自動測量。文中給出了標準樣品和吸收材料的實測結果。Abstract: A novel method involving multiple impedance measurements and optimization algorithm for the reconstruction of electromagnetic parameters is presented. Computer-aided analysis is used in all processes. Experimental results including teflon and some kinds of microwave absorbing materials are given.
-
周清一.微波測藍技術.北京:國防工業出版社,1964,第八章.[2]王相元,等.電子測量與儀器學報,1989, 4(1):43-49.[3]王相元,等.電子測量與僅器學報,1989,4(1):50-60.[4]Measuring Dielectric Constant With the HP 8510 Network Analyzer. The measurement of both permittivity and permeability of solid materials. HP Product Note 8510-3.[5]梁昌洪,等.電于學報,1990,19(3): 1-6.[6]梁昌洪.計算微波,西安:西北電訊工程學院出版社,1985,第二章.[7]鄧乃揚.無約束最優化計算方法.北京:科學出版社,1982.[8]Roussy G. The Journal of Microwave Power and Electromagnetic Energy, 1990, 25(2): 67-73. -
