改進型波束波導饋電雙鏡天線的輻射特性
RADIATION PERFORMANCE OF HIGH EFFICIENCY DOUBLF REFLECTOR ANTENNA FED BY BEAM WAVEGUIDE
-
摘要: 本文導出了地面站常用的改進型波束波導饋電高效率雙鏡天線的輻射特性的計算式。根據這些式子可以計算天線的性能;諸如主極化和交叉極化的輻射圖、波瓣峰值、半功率角常數、相位損失等等。為了適應工程上普遍性計算的要求,對上述計算式作了處理,并且根據一般工程要求進行了大量計算,得到便于在工程中應用的結論。
-
關鍵詞:
Abstract: In this paper, the equations for calculation of the radiation performances on high efficiency double reflector antenna fed by beam waveguide are derived.Using these equations, the performance of the antenna can be predicted, such as the radiation patterns, the peak values of copolarization and depolarization, the factor of half power beam width, the phase loss and so on.These equations have been reformed to meet the requirements of general engineering eomputation. Some engineering computations are made, and some useful conclusions about the antenna are obtained. -
W. F. Williams, Microwave J., 8(1965), 79.[2]章日榮等編著,衛星地面站天線新技術研究,第二章,國防工業出版社,1982年8月.[3]楊可忠,電子信息技術,1981年,第1期,第13頁.[4]M. J. Gans, BSTJ, 55(1976), 289.[5]章日榮等編著,衛星地面站天線新技術研究,第四章,國防工業出版社,1982年8月. -
