用攝動法定量研究二階鎖相環的非線性性能
A QUANTITATIVE RESEARCH OF NONLINEAR BEHAVIOUR OF A SECOND-ORDER PHASE-LOCKED LOOP BY PERTURBATION METHOD
-
摘要: 為了獲得相干啾聲信號,在壓控振蕩器上進行線性調頻,用鎖相環鎖定起始頻率的相位。對于高增益二階環,當環路參數和調頻率滿足條件01時,調頻得以實現且環路無須斷開。 本文將環路方程變換為近于線性的微分方程,用攝動法給出其漸近解析解,從而獲得了環路對調頻波形影響的定量關系。計算機模擬結果與理論分析基本吻合。
-
關鍵詞:
Abstract: It is found that the linear frequency modulation is used on a voltage-controlled oseillator and a phase-locked loop to lock its starting-frequency phase for generating a coherent chirp signal. For a high-gain second-order loop, the loop parameters and the modulating frequency rate must be chosen to satisfy the condition, O 1, and then it is possible to realize the FM on the VCO, while the loop is not necessarily broken during FM pulse.In this paper, the PLL' s equation is transformed into a nearly linear differential equation and its asymptotic solution is given by perburbation metho. Thus, the quantitative relationships about the effects of the PLL on the LFM waveform are obtained. Finally, results of simulation by means of computer show good agreement with the theoretical analysis. -
W. C. Lindaey and M. K. Simon, Phase-Locked Loop Their Application, IEEE Press. 1977, p.1-4.[2]鄭繼禹,萬心平,張厥盛,鎖相環路原理與應用,人民郵電出版社,1976年(第一版),第85-118頁.[3]B. D. Campbell, IEEE Trans. on AES, AES-6(1970), 62.[4]Shuttle Synthetic Aperture Radar Implementation Study, Vol. 1, Mar. 8. 1976, NASA-CR-147775.[6]O. E. Cook and M. Bernfeld, Radar Signals, An Introduction to Theory and Application, dcade. mic Press, New York-London 1967, Chapter 8 -
