H11O多模圓彎曲波導傳輸特性
TRANSMISSION CHARACTERISTICS OF H11O MULTIMODE CIRCULAR BENDING WAVEGUIDE
-
摘要: 近年來,N.Nakajima等對4、5、6GHz共用天線波導系統中一種高性能偏置激勵的卡塞格倫微波天線所用多模圓彎曲波導的傳輸特性及其高次波型E01O的影響進行了分析和實驗研究,而文中對彎波導所激發的另一重要高次波型H21O的影響和有效地處理方法并未解決。本文根據任意截面彎曲波導耦合波方程組分析并計算了H11O多模圓彎曲波導內高次波型耦合特性及其前兩個最重要的較低階高次波E01O、H21O的耦合系數和波型激發量,提出了一種寬頻帶H21O、E01O波型濾波器,實驗表明波型濾波器的實用效果良好,從而使N.Nakajima等遇到的并待克服的問題可基本解決。
-
關鍵詞:
Abstract: Higher order modes coupling characteristics in H11O, circular bending waveguide are analyzed according to the coupled wave equations, and coupling coeffecients of E01O, H21O, modes and their amplitudes are computed. A broad-band H21O, E01O mode filter has been presented. Experimental results indicated that its practical application is quite satis-factory. Thus, the problems presented by N. Nakajima, etc. can be solved. -
Y. Kikuchi and S. Matsumoto, J. T. R., 12(1970) 4, 267.[2]Y. Kikuchi S. Matsumoto and S. Matsuhashi, J. T. R., 13(1971) 2,69.[4]中嶼,島貫,高性能4,5,6 GHz帶用アンテナの設計,信學會通信部全國大會,昭和55年, S6-9.[7]黃宏嘉,微波原理,卷I,科學出版社,1963年,第 264-270頁.[8]M. Andresen, A. E. ., 12(1958), 414.[9]鮑玉書,電子學報,1980年,第4期,第60頁.[10]R. Levy, IEEE Trans. on MTT, MTT-16 (1968), 995. -
