光纖表面等離子體共振傳感檢測系統中的數據分析
Data Analysis in the Optical Fiber Surface Plasmon Resonance Sensing Systems
-
摘要: 該文給出了光纖表面等離子體共振(SPR)傳感檢測系統的輸出信號模型，采用偏度峰度檢驗法檢驗了其噪聲為高斯噪聲，提出采用均值估計，降低方差。進一步分析了均值估計中存在的噪聲也是高斯噪聲，采用線性模型進行估計，確定共振波長和峰值強度，結果表明經過兩次估計獲得的共振波長精度達到了光纖SPR系統中光譜儀的波長檢測精度，峰值精度達到了光譜儀的光強檢測精度。最后，分析了數據處理量和提出了優化方法，使得在微小犧牲檢測精度的前提下數據處理工作量降為原有工作量的2%，特別適用于被測對象變化急劇的情形。
-
關鍵詞:
- 光纖SPR傳感器; 噪聲分析; 均值估計; 線性估計
Abstract: The output signal model of optical fiber Surface Plasmon Resonance (SPR) sensing systems is presented in which the noise is proved as Gaussian distribution by adopting skewness and kurtosis test, so signal averaging method has been used and the stand deviation is decreased. Further, the estimated mean after signal averaging processing still includes some noise which has also been proved as Gaussian noise by using the same test method and linear estimate model is used to determine the resonant wavelength and the light intensity at the wavelength. The results show that both the wavelength and the normalized light intensity detection precisions are approximate to the ones of the used spectrometer. Finally, the optimization method on the data processing is discussed and the data processing work is decreased as 2% of the initial one by used the method, which is particularly adaptable to measure the sensing medium whose refractive index varies with time quickly. -
Salamon Z. Surface plasmon resonance spectroscopy as a tool for investigating the biochemical and biophysical properties of membrane protein systems I: Theoretical principles. Biochemical et Biophysical Acta, 1997, 1331: 117-129.[2]Abdelghnani A, Renault N J. SPR fibre sensor sensitized by fluorosiloxane polymers[J].Sensors and Actuators B.2001, 74:117-123[3]Homola J. Spectral surface plasmon resonance biosensor for detection of staphylococcal enterotoxin B in milk. International Journal of food Microbiology, 2002. 75(1-2): 61-69.[4]Akimoto T, Sasaki S, Ikebukuro K, et al.. Estimation of sensitivity for refractive index and immunoreaction in a surfaceplasmon resonance sensor probe[J].Analytica Chimica Acta.2000, 417:125-131[5]Lin W B, Lacroix M, Chovelon J M, et al.. Development of a fiber-optic sensor based on surface plasmon resonance on silver film for monitoring aqueous media[J].Sensors and Actuators B.2001, 75:203-209[6]Jorgenson R C, Yee S S. A fiber optic chemical sensor based on surface plasmon resonance[J].Sensors and Actuators B.1993, 12:213-220[7]曹振新，梁大開，郭明江. 光纖表面等離子體波傳感器中膜厚與共振波長關系的實驗研究. 光學學報, 2003, 23(1): 125-128.[8]Chinowsly T M, Yee S S. Data analysis and calibration for a bulk refractive index compensated surface plasmon resonance affinity sensor. Proc. SPIE Int. Soc. Opt. Eng, 2002, 4578 : 442-453.[9]Ober R J, Ward E S. The influence of signal noise on the accuracy of kinetic constants measured by surface plasmon resonance experiments[J].Analytical Biochemistry.1999, 273:49-59 -
