短槽混合電路功率合成器的優化設計
OPTIMUM DESIGN OF SHORT-SLOT HYBRID POWER COMBINER
-
摘要: 本文提出了用負阻非線性網絡模型來表征短槽混合電路功率合成器相互注入鎖定現象的新思想,該模型比較完整地反映了相互注入鎖定中的非線性特性,在導出了功率合成系統的非線性方程之后,給出了達到最大功率合成效率時振蕩器工作參數的優化方法。優化結果與實驗結果吻合較好。
-
關鍵詞:
- 短槽混合電路; 功率合成器; 優化設計; 相互拄入鎖定
Abstract: A new idea of representing the mutual injection locking phenomena in the short-slot hybrid power combiner by a model of negative nonlinear network is proposed. This model thoroughly represents the nonlinear characteristic of the combiner. After the nonlinear equations of the combining system are derived, a method of optimizing the parameters of the combined oscillators to achieve a maximum power combining efficiency is given. The optimum results agree with experimental ones quite well. -
Russell K J. IEEE Trans. on MTT, 1979, MTT-27(5): 472-478.[2]Chang K, Sun C. IEEE Trans. on MTT, 1983. MTT-31(2): 91-107.[3]Mizushina S. Proc[J].IEEE.1967, 55(12):2166-2167[4]Mizushina S, Kondon H, Ashiki M. IEEE Trans. on MTT, 1980, MTT-28(12): 1428-1432.[5]Ohta I Kaneko T. IEEE Trans. on MTT, 1989, MTT-37(11): 1699-1707.[6]Nakajima M, Ikenoue J. Int. J. Electron. 1978, 44(4): 465-472.[7]Fukumoto K, Nakajima M, Ikenoue J. IEEE Trans. on MTT, 1983, MTT-31: 954-959.[8]Fukumoto K, Nakajima M, Ikenoue J. IEEE Trans. on MTT, 1985, MTT-33: 319-323. -
