雙向負阻晶體管張弛振蕩器的研究
A RESEARCH ON THE RELAXATION OSCILLATOR WITH BNRT
-
摘要: 本文研究了雙向負阻晶體管(BNRT)張弛振蕩器的分段線性(具有四段折線和三段折線)動力學模型。給出了電路和動態方程。討論了張弛振蕩器的一些性質。實驗結果與計算結果一致,表明這種動力學模型是適當而有效的。
-
關鍵詞:
Abstract: In this paper a piecewisely linear (with three or four segments) dynamic version for the relaxation oscillations in a circuit with Bidirectional Negative Resistance Transistor (BNRT) is studied. The circuit and the dynamic equations are given and some properties of the relaxation oscillations are discussed. Experimental results agree with the computations, showing that the dynamic model is adequate and useful. -
李風銀等,電子學報,12(1984), 110.[2]李鳳銀等,半導體學報,5(1984),698.[3]山本外史,バルスとデイジタル回路,理工學社,(1978), 103-109. -
