變厚度非平面介質罩發散系數的計算幾何光學法
CALCULATION OF THE DIVERGENCE FACTOR OF DIELECTRIC CONFORMAL DOME PHASED ARRAY ANTENNA--GEOMETRIC OPTICS METHOD
-
摘要: 介質共形頂相控陣天線利用變厚度介質透鏡改變相控陣波束掃描方向,理論上來說可到達半空域或更大,是一種適用于彈載、機載雷達系統的天線。本文較詳細地討論了介質罩對電磁波的發散系數的計算,給出了分析非平面變厚度分層介質對電磁波反射、折射的兩種有效方法,并進行了比較。
-
關鍵詞:
- 共形陣; 相控陣天線; 幾何光學法; Jacobi式; 曲率矩陣
Abstract: Dielectric conformal dome phased array antenna uses the dielectric dome to change the direction of the scanning beam. It is supposed to widen the scan-range of planar phased array to half spherical space or more. It is suitable for missiles and air-borne radars. When analysise its scanning characteristics, the divergence factor(DF) of the dome must be calculated. This paper provides two methods to study the DF which are based on geometrical optics, and compares them. These methods are very useful in studying the reflection and the refraction of the non-planar layered dielectric. -
Stangel J J, Valenfine P A. Phased array fed lens antenna. U. S. Patent, 3755815, Aug. 28, 1973.[2][2][3]Stangel J J, Valenfine P A. The dome antenna. Microwave Journal, 1975, 18(10): 31-34.[4]杜耀惟.天線罩電信設計方法.北京:國防科技出版社,1993,第二、六、七章.[5]Overfelt P L. Superspheroids: A new family of radome shapes. IEEE Trans. on AP, 1995, AP-43(2): 215-220.[6]柴舜連,劉熒,姚德森,毛鈞杰,秦凌飛.介質共形頂相控陣的研究.電子學報,1997,已錄用.[7]Gordon Richard K, Mittra Raj. Finite element analysis of axisymmetric radomes. IEEE Trans. on AP, 1993, AP-41(7): 975-981.[8]汪茂光.幾何繞射原理.西安:西北電訊工程學院出版社,1985.[9]Keller J B, Keller H B. Determination of reflected and transmitted field by geometrical optics[J].Journal of the Optical Society of America.1950, 40(1):48-52[10]Shung Wu Lee, Mysore S Sheshadri,et al. Refraction at a curved dielectric interface: Geometric optics solution. IEEE Trans. on Microwave Theory and Techniques, 1982, MTT-30(l): 12-19.[11]Deschamps G A. Ray techniques in electromagnetic[J].Proc. IEEE.1972, 60(9):1022-1035 -
