雙層手征介質板中電偶極天線的輻射特性
THE RADIATION CHARACTERISTICS OF ELECTRIC DIPOLE ANTENNA IN TWO-LAYER CHIRAL SLABS BOUNDED BY A PERFECTLY CONDUCTING PLANE
-
摘要: 本文首先給出了電流源激勵下雙層手征介質中的并矢格林函數表達式。應用鞍點積分法，導出了有金屬板襯底的雙層手征介質中電偶極天線的輻射場表達式。分析了有、無空氣隙時手征導納對電偶極天線的方向圖，＝0方向的最大場強和諧振頻率的影響程度。結果表明，通過改變手征導納參數，可以有效地調節電偶極天線的輻射特性。
-
關鍵詞:
- 電偶極天線;手征介質;手征導納;方向圖
Abstract: The formulas of dyadic Greens function for two-layer chiral electric dipole antenna are derived at first, and using the method of saddle-point integration,the expression of radiation field of electric dipole antenna is also derived. The ef fects of chirality admittance on the radiation pattern, maximum fields in the direction ＝0and resonance frequencies are examined. The results show that chiral media have potential applications in antenna areas. -
Engheta N, et al. Microwave and Optical Technology Letters, 1992,5(1):31-34.[2]Toacano A, et al. J. Elect. Waves and Applic., 1992, 6(5/6): 751-759.[3]尹文言,等.電波科學學報,1993,(1): 29-36.[4]鐘順時.微帶天線理論和應用.西安:電子科技大學出版社,1991年6月. -
