金屬柵厚度對介質波導漏波天線輻射特性的影響
EFFECT OF METALLIZATION THICKNESS ON MILLIMETER WAVE LEAKY-WAVE ANTENNAS
-
摘要: 本文研究了厚金屬柵加載介質插入波導漏波天線的輻射特性,運用電磁場的網絡解析法的推廣模型建立起本征值方程。數值結果表明,金屬柵厚度對漏波天線波求方向影響較小,但對漏波天線的輻射效率和波束寬度有明顯的影響。
-
關鍵詞:
- 漏波天線; 等值電路; 復傳播常數
Abstract: The effect of metallization thickness on a leaky wave antenna based on a metal-strip-loaded dielectric insert waveguide is investigated. The intrinsic equation is set up by. the extended version of the network analytical method of electromagnetic field. Numerical results show that the effect of metallization thickness is smaller on the direction of main beam and very noticeable on the beamwidth and aperture efficiency. -
Rlohn R L,et al. IEEE Trans. on AP, 1979, AP-38(10): 764-773.[2]Solbach K. E-band leaky wave antenna using dielectric image line with etched radiating elements, IEEE MTT-S Int. Microwave Symp. Digest, Orlando FL, 1979,[3]pp. 214-216.[4]Mittra R, et al. IEEE Trans. on AP, 1981, AP-29(4): 652-654.[5]Trinh T N. et al. Horn image guiee leaky-wave antenna, IEEE MTT-S Inr. Microwave Symp. Digest. Los Angeles:(1981), 20-22.[6]Encinar J A. IEEE Trans. on AP, 1990, AP-38(9): 1405-1412.[7]Guglielmi M, et al. IEEE Trans. on AP, 1991, AP-39(4): 497-504. -
