高模式純度H○02波波型變換器
A HIGH PURITY H○02 WAVE TRANSDUCER
-
摘要: 本文所述的H○02波波型變換器由中心激勵型H10H○02波波型變換器、H02波過渡器和H10波過渡器三部分組成。文中對上述有關部分分別列出了設計公式,給出了計算結果。在8mm波段實測的結果表明:這種變換器在 3238 GHz頻帶內,對H○01波的抑制在 30dB以上。
-
關鍵詞:
Abstract: The H○02 mode transducer described in the paper consists of three parts: centre-excited type H10H○02 transdueer, H○02 mode taper and H10 mode taper. The design formulae of the relative parts are derived and the results obtained are given. The practical measurement at 8 mm band has been completed. It shows that the rejection to H○01 mode of the transducer is about 30 dB in 32-38GHz. -
Shuich Sbindo, IEEE Trans.on MTT, MTT-24(1976), 525.[3]Kunio Hashimoto, IEEE Trans. on MTT, MTT-24(1976), 25.[4]Nobus Suznki, R. E. C. L. 24(1976), 429.[5]黃宏嘉,微波原理,卷Ⅱ, 科學出版社,1963年,第430頁.[6]L. Solymar, PIEE, 106(1959) Part B Suppl. No. 13, p. 121 -
