GaInAsP/InP雙異質結液相外延片的p-n結偏位
MISPLACED p-n JUNCTION IN D. H. GaInAsP/InP WAFER GROWN BY LPE
-
摘要: 用掃描電鏡電子束感生電流法研究了GaInAsP/InP雙異質結液相外延片的p-n結偏位問題。認為Zn沾污是偏位的主要原因之一。用控制Zn的摻入量或用Mg作p型摻雜劑均可制得正常的p-n結。用電化學c-v法測試了部分樣品,并與制管后發射光譜進行比較,結果相同。
-
關鍵詞:
Abstract: Misplaced p-n junetion in the LPE D. H. GaInAsP/InP wafer is investigated by scanning electron microscope and electron beam-induced current method. It is shown that one of the reasons for the misplaced p-n junetion is Zn contamination. By controlling doping level of p-type dopant Zn, or using Mg as p-type dopant, the correctly located p-n junetion is obtained. The locations of the p-n junetion of some samples are measured by electrochemical c-v method. The results obtained are consistent with the emission spectrum of the LED fabricated from the wafers. -
Y.Takamashi, et al., Jap. J. Appl. Phys., 18(1979).1615.[3]K.Iga, et al., IEEE J. on QE. QE-15 (1979), 707.[5]J. J. Coloman, et al., Electron Lett., 14(1978), 558.[6]鄔祥生等,液相外延生長1. 3 um, GaInAsP/InP雙異質結,半導體學報,(待發表)。[7]H. Grothe, et al.,Electron Lett., 15(1979), 702.[10]陳自姚等,半導體光電,1981年,第2期,第207頁.[11]H.D. Law., IEEE. J. on QE, QE-18(1979), 549. -
