變形電子束曝光機成形偏轉器的設計和性能
DESIGN AND PERFORMANCE OF SHAPING DEFLECTORS FOR VARIABLE SHAPED ELECTRON BEAM LITHOGRAPHY
-
摘要: 在變形電子束曝光機中,為使曝光均勻必須保證靶上束斑電流密度物邊緣分辨率不隨束斑形狀和尺寸的變化而改變。實現這一目標的關鍵是正確設計成形偏轉器。本文討論采用高靈敏度平行板偏轉器實現成形偏轉時,為達到上述目標應進行的線性補償和旋轉補償?shù)脑O(shè)計計算方法。給出了用實驗方法改變電子源象與偏轉板幾何中心的軸向距離所測得的線性補償因子和旋轉補償因子的值。實驗結果與計算值符合較好。
-
關鍵詞:
- 電子束曝光機; 電子光學; 偏轉器
Abstract: In order to obtain uniform exrnosure in variable shaped electron beam lithography, the beam current density and edge resolution on the target must not change for different spot shapes and sizes. The key to the goal is the anpropriate design of shaping deflectors. A linear and rotation compensation approach is presented. Values of linear and rotation compensation factors versus the distances between electron source image and centers of deflectors are measured on an experimental electron beam column with variable spot shaping. The experimental results are in good agreement with the calculated ones. -
G .Cogswell et al., Proc.8th International Conference on Electron and Ion Beam science and Technology,1978,PP.117-133.[2]M. Fujinami et al., J.Vac.Sci.Technology, 19(1981),941-945.[3]R. D. Moore, et al., J.Vac.Sci.Technology, 19(1981), 950-952.[4]S. Moriya, et al., J.Vac.Sci.Technology, B1(1983),990-994.[5]K. Nakamura, et al., J.Vac.Sci.Technology, B3(1985),94-97.[6]H. K.King, et al., J.Vac. Sci. Technology, B3(1985),98-101.[7]E. de Chambost, et al., J.Vac.Sci.Technology, B4(1986), 78-82.[8]M. Fujinami, et al., J.Vac. Sci.Technology, B5(1987),61-65.[9]R.Yoshikawa,et al.,J.Vac. Sci.Technology, B5(1987),70-73.[10]S.Tamamushi, et al., J.Vac Sci.Technology, B6(1988),209-212.[11]H .C. Pfeiffer, J.Vac. Sci. Technology, 15(1978),887-890.[12]江鈞基,電子科學學刊, 8(1986),359-366. -
