一維菲涅爾區相位修正平面反射器的聚焦特性研究
RESEARCH ON THE CAUSTIC CHARACTERISTICS OF ONE DIMENSIONAL FRESNEL ZONE PHASE CORRECTED PLATE REFLECTOR
-
摘要: 在平面上沿某一個方向進行1/P波長的相位修正,可以構成一維菲涅爾區相位修正平面。由此而得到的平面反射器可作為拋物柱面反射器的替代物來構成扇形波束天線。本文用物理光學法分析了平面波入射時該結構的聚焦特性,并給出了一組焦散區場分布的數值計算結果。
-
關鍵詞:
- 反射面天線; 聚焦特性; 菲涅爾區相位修正平面; 扇形波束天線
Abstract: One dimensional Fresnel zone phase corrected plate (1-DFP) can be made by a 1/P wavelength phase correcting along one dimension upon the plate. When it is used as a reflector, it gives an alternative to parabolic cylinder reflector in application on fan-beam antenna. In this paper, Physical Optics (PO) is used in analyzing the caustic characteristics of 1-DFP reflector with plane wave illumination. Numerical results of a series of fields in caustic are also presented. -
Garrett J E Wiltse J C. Inc[J].J. Infrared MM Waves.1991, 12(3):195-220[2]Buder B, Menzel W. Electronics Lett., 1988, 24(6):318-319.[3]Guo Y J, Barton S K, Wrighr T M B. Design of High Efficiency Fresnel Zone Plate Antennas, IEEE AP-S91, USA: Vol.1,1991, 182-185.[4]Delmas J J. TDF Antenna for Multisatellite Reception Using Fresnel Principle in Three Dimensions, Proc. 1SAP92, Japan: 1992, 321-324. -
