在迴旋管中采用中等偏心率橢圓橫截面諧振腔的探討
THE RESEARCH OF RESONANT CAVITY W1TH ELLIPTICAL CROSS-SECTION AT MODERATE ECCENTRICITY IN GYROTRON
-
摘要: 本文綜述了幾種在迴旋管中采用大橫截面諧振腔的辦法,計算了中等偏心率橢圓波導各TE模的歸一化截止頻率。歸一化截止頻率的數據表明,用橢圓橫截面諧振腔的迴旋管具備以下特性:(1)諧振腔體積大;(2)可以振蕩的工作模式少;(3)可以使用大直徑電子束;(4)可以工作于低次角向腔模。
-
關鍵詞:
Abstract: In this paper, several types of resonant cavities with large transverse cross-section used in gyrotron are briefly reviewed. The method of caleulating the cutoff frequeneies of TE mode of elliptical waveguides with moderate eccentricities is given. From the cal-culated data of cutoff frequencies, it is shown that the gyrotron with elliptical cavity has the following characteristics: (1) a large volume cavity can be used; (2) the dcn-sity of modes which can oscillate is rare; (3) it is allowable to use an electron beam with a large diameter; (4) it is possible to use a cavity mode with low azimuthal number. -
A. V. Gaponov, Int. J. Electronics, 51(1981)4, 277.[2]L. J. Chu, J. Appl. Phys., 9(1938), 583.[3]J. G. Kretzschmar, IEEE Trans. on MTT, MTT-18(1970), 547.[4]N. W. McLachlan, Theory and Application of Mathieu Functions, Oxford, 1947. -
