雙向負阻晶體管動態伏安特性的實驗研究
STUDY ON THE DYNAMIC I-V CHARACTERISTICS OF BNRT
-
摘要: 本文研究了雙向負阻晶體管(Bidirectional Negative Resistance Transistor,簡稱BNRT)在張弛振蕩電路中的動態伏安特性。借助動態伏安特性對BNRT張弛振蕩電路的一些性質進行了分析。實驗結果與計算結果一致。本文還對改進器件結構的設計,以便使器件達到更高的振蕩頻率提供了理論依據。
-
關鍵詞:
- 半導體器件; 負阻器件; 張弛振蕩器
Abstract: Experimental investigation was carried out for the dynamic I-V characteris-tics of the bidirectional negative resistance transistor (BNRT) in the relaxation oscillation circuit. Some properties of the BNRT relaxation oscillation circuit were also analysed by means of the dynamic I-V characteristics. Experimental results agree with the computations. The direction for improving the device design is also pointed out in order to enhance the oscillation frequency. -
李鳳銀,周旋,李錦林,曹體倫,電子學報,1984年,第4期,第112頁.[2]李鳳銀,周旋,李錦林,曹體倫,半導體學報,5(1984)6,698-701.[3]周旋,鮑秉乾,電子科學技術,15(1985)5,4-7.[4]余道衡,電子科學技術,17(1987)5,33-36.[5]裴留慶,郭汾,謝劍光,自然數周期序列與混沌,中國第七屆電路與系統年會論文集,1987年,深圳, 13-18頁.[6]余道衡,朱照宜,電子科學學刊,9(1987)2,176-180.[7]Wang Shou-wu, et al., PIEE, 69(1981), 130-139.[8]J. Millman, H. Taub, Pulse, Digital and Switching Waveforms, McGraw-Hill Book Co. Chapter 6, (1965).[9]劉文生,李錦林,取樣技術原理與應用,科學出版社,1981年,第153-156頁. -
