偏心環微帶天線諧振特性的研究
ANALYSIS OF RESONANT CHARACTERISTIC ON ECCENTRIC RING MICROSTRIP ANTENNAS WITH ARBITRARY SHAPE
-
摘要: 本文用點匹配法分析了偏心環微帶天線的諧振特性,所得公式可將圓形、同心圓環和偏心圓環微帶天線作為特例來應用.對偏心圓環諧振波數的理論計算與實驗測試的良好一致性表明,這種方法適用于分析任意形狀微帶天線的諧振特性.偏心圓環較之同心圓環有較寬的帶寬.
-
關鍵詞:
- 微帶天線; 諧振特性; 帶寬; 偏心圓環; 點匹配法
Abstract: Resonant characteristic of eccentric ring microstrip antennas has been studied using point-matching moded. The formulation can be appplied to some specific cases, for example, circular, circular ring and eceentric circular ring patch antenna. The good agreement between measured and calculated results of resonant wave-number of eccentric circular ring microstrip antenna indicates that the method can be used to analyse characteristic of arbitrary shape microstrip antennas. -
I. J. Bahl, S. S. Stuchly, M. A. stuchly IEEE Trans. on MTT, MTT4B(1980)12, 1464-1468.[2]W.C. Chew, IEEE Trans. on AP, AP-30(1982)5, 918-922.[3]I. S. Dahel, K. F. Lee, Electron Lett,18(1982)24, 1051-1052.[4]J. W. Mink, Circular Ring Microstrip Antennas Elements, Presented in 1980 AP Soc., Int. Symp, Quebec, Canada, June, 1980, pp. 605-608.[5]I. J. Bahl, P. Bhartia 著, 梁聯伸,冠廷耀譯. 微帶天線, 電子工業出版社,1985年3月,第98-103頁,第114-117頁.[6]Rao Qinjiang Resonant Frequencies of Arbitrary Shaped Microstrip Patch Antennas, IEEE-APS International Symposium, 1992 Digest, Chicago, USA, Vol. 3, pp. 1745-1748.[7]林昌祿, 天線測量技術. 成都電訊工程學院出版社, 成都, 1987年, 第二章.[8]Rao Qinjiang Double-Frequencies Characteristic of Ridged Circular Microstrip Patch Antennas IEEE APS International Symposium, 1992 Digest, Chicago, USA, Vol. 3, pp. 1473-1474. -
