雙注入型磁敏二極管的設計
A DESIGN OF DOUBLE INJECTION TYPE MAGNETO-DIODE
-
摘要: 本文探討了在P+IN+型長二極管的一個側面設置高復合區的鍺磁敏二極管的設計,給出了選擇長度、厚度、寬度和電阻率()的最佳設計關系式: /w(l/d)310.75(△T)2/I03Rth2,式中 △T為磁敏二極管的最大溫升,Rth為管子的熱阻,I0為通過管子的偏流。
-
關鍵詞:
Abstract: A new design is proposed for long P+IN+ type Ge magnetodiode with a high recombination region on one side. The optimal relation is established between its length (l), depth (d), width () and resistivity () for designing Ge magnetodiode: (/) (l/d)3=10.75(△T)2/(I03Rth2) △T is the limit of chip temperature rise, Rth the thermal resistance, I0 the current flowing through diode. -
В.И.Стафеев,ЖТФ, 28 (1958), 1631.[2]В.И.Стафеев,ФТТ, 1(1959), 848.[3]З.И.Каракушан, ФТТ, 3(1961), 677.[4]山田,電子材料,8(11), 1969, p. 92.[5]新井,山田,電子材料,10(12), 1971, p. 61.[6]I.I. Munteanu, Rev. Roum. Phys., 18(1973), 323.[7]黃得星,電子學報,1980年,第4期,第43頁.[8]M. A. Lampert and A. Rose, Phys, Rev., 121(1961), 26.[9]M. A. Lampert, ibid., 125(1962), 126.[10]R. Hirota, S. Tosima and M. A. Lampert, J. Phys. Soc. Japan, 18(1963), 535. -
