不規則邊界問題的區域分解法
CONTRIBUTIONS TO IRREGULAR BOUNDARY PROBLEMS
-
摘要: 本文根據明晰的物理概念,提出了求解具有不規則邊界傳輸線特性阻抗的區域分解法。實際上,這是將不規則邊界問題的求解工程化,也就是把不規則邊界問題分解為比較規則圖形的邊界問題來處理。為了說明方法的具體運用,文中分析了特殊截面?zhèn)鬏斁€問題,并通過與文獻中的結果比較和理論分析,以證實其準確性和實用性。
-
關鍵詞:
Abstract: A method is presented for a practical solution of irregular boundary problems. In this method, the irregular boundary is treated as a combination of several simple boundary value problems, which can be solved easily and exactly. To illustrate the application of the method, the characteristic inpedances of some transmission lines with special cross-section are computed. The accuracy of the method is confirmed by comparing the values obtained here with those reported in the literature. -
M.Gunston, Microwave Tansmission Line Impedance Data, VNR, London, 1972.[2]林為干,微波理論與技術,科學出版社,1979.[3]R. Levy, IEEE Trans. MTT, MTT-28 (1980), 369.[4]林為干,鐘祥禮,物理學報,19(1963),249.[5]林為干,曾令儒,同上,30(1981),12.[6]曾令儒,中國科學(A輯),1982年,第6期,第553頁.[7]曾令儒,同上1983年,第4期,第357頁.[8]E. Cristal, IEEE Trans. MTT, MTT-12 (1964), 428.[9]梁昌洪,官伯然,電子學報,1984年,第5期,第1頁.[10]曾令儒,物理學報,31(1982), 840.[11]H. Riblet, IEEE Trans. MTT, MTT-20 (1972), 538.[12]T. Chen, ibid., MTT-8 (1960), 510.[13]潘生根,中國科學(A輯),1986年,第9期,第999頁.[14]S. G. Pan(潘生根), IEEE Trans. on MTT, MTT-35 (1987), 61. -
