晶體管非線性失真分析
NONLINEAR DISTORTION ANALYSIS OF BIPOLARTRANSISTOR
-
摘要: 本文從器件物理和結構上提出雙極型晶體管非線性失真模型。模型包含8個參量:(1)有效基區展寬效應;(2)發射極電流集邊效應;(3)基區電導調制效應;(4)發射結電阻的非線性效應;(5)發射結電容的非線性效應;(6)集電結電容的非線性效應;(7)寄生電容的非線性效應;(8)電流放大系數和雪崩倍增效應與電壓的非線性關系。利用Taylor級數展開分析各模型參數,并編制了計算程序,定量計算了互調失真與工作頻率、發射極條寬、基區寬度、發射極線電流密度,基區摻雜濃度等重要參數的關系。計算結果與實驗結果基本吻合。
-
關鍵詞:
- 晶體管; 失真; 非線性分析
Abstract: An AC small-signal transistor model incorporating 8 nonlinearities using Taylor series representations is described. Based on this method, a nonlinear distortion-analysis program has been developed. It is used to compute the third-order intermodulation distortion IMs. The relations between IM3 and the operating frequency, emitter and base widths, emitter line current density and doped impurity concentration on base are obtained. -
S. Narayanan, Bell Sys. Tech. J., 46(1967)5, 991-1024.[2]J. T, Chea, C. P. Snapp, IEEE Trans, on MTT, MTT-27(1979), 423-430.[3]H. C. Poon, IEEE Trans, on ED, ED-19(1972), 719-739.[4]Y. L. Kao, IEEE Trans, on CT, CT-20(1973), 709-716.[5]H. Abraham, R. G. Meyer, IEEE Trans, on ED, ED-23(1976), 1290-1299.[6]O. Muler, Proc. IEEE., 58(1970)7, 1112-1121.[7]陳星弼,唐茂成,晶體管原理與設計,成都電訊工程學院出版社,1987年. -
