背腔式窄縫天線在有耗介質中的特性
CHARACTERISTICS OF THE CAVITY-BACKED NARROW SLOT ANTENNA IN A LOSSY MEDIUM
-
摘要: 本文利用矩量法與并矢格林函數相結合,研究了背腔式窄縫天線在有耗介質中的特性。對于矩陣單元的雙重級數,采用泊松求和公式改善了級數的收斂性;對于矩陣單元的二重積分,分別采用積分中值定理及橢圓積分予以簡化。本文的數值結果分別給出了有耗介質及天線結構參數對輸入阻抗的影響,為天線設計提供了依據。
-
關鍵詞:
- 背腔式縫隙天線; 有耗介質; 矩量法; 并矢格林函數
Abstract: The study of characteristics of the cavity-backed slot antenna in a lossymedium is given by using the moment method and dyadic Green s functions. The Poisson summation formula is used to convert the double series of the elements into a more rapidly converging series, and the integration middle value theorem and elliptic integral are used to simplify the double integral of the elements. Numerical results show the effects of the lossy medium and antenna parameters on input impedance, which could be used in designing cavity-backed slot antenna. -
T. M. Smith et al., IEEE Trans. on AP, AP-12(1964)3, 285-288.[2]M. H, Colien, J. Appl. Phys., 25(1954)7, 581-587.[3]J. Galejs, IEEE Trans. on AP, AP-11(1963)2, 119-126.[4]J. Galejs, Antennas in Inhomogeneous Media, Pergamon Press Ltd., Oxford, (1969),PP, 84-95.[5]C. R. Cockrell, IEEE Trans. on AP, AP-24(1976)3, 288-294.[6]S. A. Long, IEEE Trans. on AP, AP-23(1975)1, 1-7.[7]S. A. Long, IEEE. Trans. on AP, AP-25(1977)6, 829-833.[8]A. Hadidi, M. Hamid, IEE Proc.-H, 136(1939) 2, 139-146.[9]R J. Gilmore et al., Enhanced Saturation Determination Using the EPT-G Endfire Antenna Array, SPWLA 28th Ann. Logging Symp., London, June 29-July 2, (1987).[10]E. Lier, IEEE Trans. on AP,AE38(1990)6, 783--792.[11]吳信寶,電磁波傳播測井中的天線與波傳播理論研究,電子科技大學博士論文,成都,1991年.[12]數學手冊編寫組,數學手冊,人民教育出版社,北京,1979年,第600-606頁. -
