一種新型的5GHz自適應偏置及可變?cè)鲆娴驮肼暦糯笃?/h2>
A New 5GHz Adaptively-Biased and Variable Gain Low Noise Amplifier
-
摘要: 該文提出了一種新型的自適應偏置及可變?cè)鲆娴驮肼暦糯笃?LNA)，利用電荷泵(亦稱電壓倍增器)將LNA輸出信號轉換成與LNA射頻輸入信號功率成比例變化的直流信號，以此信號同時反饋控制LNA的偏置和增益，來實現自適應偏置以及可變?cè)鲆娴驮肼暦糯笃? 從而極大地改善了LNA的輸入線性范圍。鑒于5GHz頻率下，Bipolar相對于CMOS更好的頻率特性和低噪聲特性，該項研究采用了BiCMOS工藝，實現了低于3.0dB的噪聲系數(高增益狀態下)和大約13dBm的輸入三階交調點IIP3的控制范圍以及大于15dB的增益控制范圍。
-
關鍵詞:
- 低噪聲放大器;自適應偏置;可變?cè)鲆?電荷泵
Abstract: In this paper, a new Low Noise Amplifier (LNA) with adaptive-biasing and variable gain is presented, in which charge pump is used to convert the RF output signal of LNA into a dc control signal, the amplitude of which should be proportional to the input RF magnitude. By using this signal to control bias and gain of LNA simultaneously, the linearity of LNA is greatly improved. In 5GHz frequency, bipolar transistors exhibit better frequency and noise performance, so in this paper, BiCMOS technology is used. The LNA exhibits a noise figure of no more than 3.0dB (in the high gain mode), about 13dBm IIP3 improvement and gain tuning range of more than 15dB. -
