W波段寬帶機械調諧體效應振蕩器
W-BAND GUNN OSCILLATORS WITH WIDE MECHANICAL TUNING RANGE
-
摘要: 本文介紹利用WT57 GaAs體效應管研制的W波段寬帶機械調諧振蕩器。連續調諧范圍為75110GHz。在帶寬為10--15GHz的中心頻段,可輸出大于10mW的功率。并對振蕩器的偏壓電子調諧特性進行了實驗研究。Abstract: Continuously tunable 75-110 GHz Gunn Oscillators have been developedwith WT 57 GaAs diodes. In most cases, the oscillators can offer 10-20 mW output power over a bandwidth of 10-15 GHz. The characteristics of bias electronic tuning are tested using the bias sweep method.
-
J. E. Carlstrom et al., IEEE. Trans. on MTT, MTT-33(1985) 7, 610-619.[2]A. Rydberg, Int. J. Infrared and Millimeter Waves, 11(1990) 3, 383-403.[3]薛呈添,王喬敏,電子科學學刊,11(1989)2,215-220.[4]陳效建,固體微波,1978年,第6期,第9-13頁.[5]鄧衍茂,固體電子學研究與進展,6(1986)3,189-195.[6]K. H. Doring, E. Seebald, Electron. Lett., 16(1980) 1, 50-51.[7]Dorado Co., Microwave Journal, 31(1988) 5, 398. -
