高功率低速度零散單陽極磁控注入電子槍的研究
基金項目:
中國科學院知識創新項目資金資助課題
Study of a High-Power Single-Anode Magnetron Injection Gun with Low Axial Velocity Spread
-
摘要: 該文利用基于絕熱壓縮原理和角動量守恒理論的解析方程組，在對電子槍相關參量分析的基礎上，研究一種陰極采用鼻狀輔助聚焦極的單陽極磁控注入電子槍。通過電子光學軟件EGUN-226對電子槍結構進行優化設計，比較分析了不同橫縱速度比對電子注軸向速度零散的影響。結果表明這種結構的電子槍可以適應比較大的電流應用。
-
關鍵詞:
- 單陽極; 磁控注入電子槍; 回旋管
Abstract: According to a set of analytic equations based on adiabatic compression theory and angular momentum conservation, a single-anode Magnetron Injection Gun(MIG) with a nose-shape accessorial focus pole is studied in this paper. The parameters of the single-anode MIG are optimized through computer simulation with an electron trajectory code (EGUN226). The effect of the ratio of transverse velocity and longitudinal velocity on axial velocity spread is analyzed, which shows that a high-quality electron beam with large and low axial velocity spread can be realized for large current application. -
Barker R J, Schamiloglu E. High-power Microwave Sources and Technologies. New York, IEEE Press, 2001: 155-196.[2]Lawson Wes, Specht Vicki. Design comparison of single-anode and double-anode 300-MW magnetron injection gun[J].IEEE Trans. on Electron Devices.1993, 40(7):1322-1328[3]Baird J M, Lawson Wes. Magnetron injection gun (MIG) design for gyrotron applications[J].Int. J. Electronics.1986, 61(6):953-967[4]Nguyen K T, Danly B G, et al.. Electron gun and collector design for 94-GHz gyro-amplifiers[J].IEEE Trans. on Plasma Sci.1998, 26(3):799-813[5]Lee S H, Choi J J, Han W K, Baek S W. An iron-free magnetron-injection-gun for a 28GHz, 200kW gyroklystron amplifier[J].Int. J. Infra. and MM Waves.1999, 20(12):2011-2022[6]Yi Sheng Yeh, Ming Hsiung Tsao, Han Ying Chen and Tsun-Hsu Chang. Improved computer program for magnetron injection gun design[J].Int. J. Infra. And MM waves.2000, 21(9):1397-1415[7]Jin J Choi. Design of a temperature limited single-anode magnetron injection gun[J].Int. J. Infra. and MM Waves.1999, 20(2):239-252[8]劉本田. 新型高效率二次諧波寬帶可調復合互作用回旋管[J].電子與信息學報.2006, 28(4):760-764瀏覽[9]Herrmannsfeldt W B. Electron trajectory program. Standford Linear Accelerator Center Report SLAC-226, 1979. -
