任意橫截面形狀同軸線的高次有限元分析
HIGH-ORDER FINITE-ELEMENT ANALYSIS OF VARIOUS COAXIAL LINES WITH ARBITRARY CROSS-SECTIONS
-
摘要: 本文用高次有限元分析了任意橫截面形狀同軸線特性阻抗;給出了一個用二次元求解同軸線特性阻抗的通用程序。由于提出了一種便于編制通用程序的計算機自動區域剖分方法,使整個分析過程十分簡便有效,大大提高了解題效率。文中對十余種不同橫截面形狀同軸線特性阻抗的計算,有力地證實了該程序的可靠性,通用性和準確性。同時,在數值分析的基礎上,對高次元的解題效能進行了討論。
-
關鍵詞:
- 同軸線; 特性阻抗; 高次有限元分析
Abstract: The high-order finite-element method is used for analyzing the characteristic impedances of the coaxial lines with arbitrary cross-sectons. A standard program with second order element analysis for calculating the characteristic impedances of various coaxial lines is developed. A computer automatic division technique is proposed to faciliate the development of the general program. As a result, the whole analysis procedure becomes simple and the solusion efficency raises tremendously. The calculations of the... -
Lin Weigan, IEEE Trans.on MTT, MTT-30 (1987,) 11, 1981-1988.[2]Pan Shenggen, IEEE Trans. on MTT, MTT-36 (1988)5,917-921.[3]林為干,物理學報,30(1981)1，12-21.[4]林為干,微波理論與技術,科學出版社,北京,1979年.[5]H.J.Rilblet, IEEE Trans. on MTT, MTT-23 (1975)8,714-715.[6]Wulu Chang, Frequenz, 43 (1989) 10, 271-276.[7]徐善駕,電子學通訊, 4(1982)4, 222-234.[8]徐善駕,彭松村,通信學報,6(1985)4,62- 69. -
