基于知識(規則)的高層次工藝映射方法

馬聰; 王作建; 劉明業

基于知識(規則)的高層次工藝映射方法

計量
- 文章訪問數: 1964
- HTML全文瀏覽量: 80
- PDF下載量: 422
- 被引次數: 0
出版歷程
- 收稿日期: 1999-01-29
- 修回日期: 1999-07-28
- 刊出日期: 2001-05-19

A METHODOLOGY OF HIGH-LEVEL TECHNOLOGY MAPPING BASED ON KNOWLEDGE

摘要

摘要: 該文研究高級綜合結果與后端工藝的銜接問題。提出一種基于知識的高層次工藝映射方法。深入研究其中知識表示、知識運用和知識獲取等各個重要環節。包括:(1)提出一種表達電路結構知識的擴充產生式表示;(2)提出基于超高速硬件描述語言(VHDL)的工藝映射知識獲取方法;(3)給出知識運用的求解控制策略和算法;(4)提出一種能查出冗余性和矛盾性的半自動知識庫維護方法;(5)提出將算法嵌入知識系統,降低知識庫復雜度的實用化方法。所實現的系統已完成與三種工藝銜接,驗證了本文工作。
- 高級綜合; 工藝映射; 超高速硬件描述語言（VHDL）; 高層次工藝映射; 知識庫; 知識表示
Abstract: This Paper is focused on the research of connecting the HLS(high level synthesis) result to the technology of IC. A knowledge-based high level technology mapping methodology is proposed, based on the traditional technology mapping theory. The method is discussed from the views of knowledge representation, knowledge acquirement and knowledge utilization, including: (1) initiating an expanded production representation approach for the knowledge of circuit structure; (2) presenting a technology mapping knowledge acquirement technique based on VHDL; (3) giving the controlling tactics and algorithms in knowledge utilization; (4) presenting a half-automatic method for KB(knowledge base) maintenance, with which, the contradictory and the redundancy in KB can be found; (5) raising a practical method that embeds the algorithms into the knowledge-based system, in order to reduce the complexity of the KB. This system has been connected to 3 kinds of IC production line, and this verifies the theory and method of the paper.

HTML全文

參考文獻(1)

馬聰.劉明業等, VHDL高級綜合與底層物理設計的銜接,電子學報, 1998,26(2),71-73.[2]R.Ang.N.Dutt,An algorithm for allocation of functional units from realistic RT component libraries,7th Int.Symp.High-Level Synth,1994,164-169.[3]E.A.Rundensteiner,D.D.Gajski,Component synthesis form function descriptions,IEEE Trans.on CAD,ICSyst.,1993,12(9),1287-1299.[4]劉明業等,專用集成電路(ASIC)高級綜合理論,北京,北京理工大學出版社,1997,179-238,307-366.[5]R.K.Brayton,R.Camposano et al.The Yorktown Silicon Compiler,In Slicaon Compilation,D.D.Gajski(Ed),Addison-Wesley,Reading,MA,1988,204-311.[6]Gwo-Dong Chen,D.D.Gajski,An intelligent component database for behavioral synthesis,Proc.of the 27th Design Automation Conference,IEEE/ACM,Orlando Florida,1990,150-155.[7]N.V.Zanden,D.Gajski,MILO:A microarchitecture and logic optimizer,Proc.of the 25th Design Automation Conference,IEEE/ACM,Anaheim Convevtion Center,1998,403-408.[8]A.R.Baseer,M.Balakreshnan et al,FAST:FPGA Targeted RTL structure synthesis technique,7th International Conference on VLSI Design Calcutta,Idia. [9]A.R.Naseer.M.Balakrishnan et al[J].,Delay minimal mapping RTL structures onto LUT based FPGAs:Field Programmable Logic and Applications,5th International workshop,FPL95,Proceddings,Oxford,UK,29 Aug-1 Sept.1994,1995:139-141[9]M.Vootukuru,R.Vemuri et al.,Resource constrained RTL partition for synthesis of multi-FPGA designs,Proceedings Tenth International Conference on VLSI Design,Hyderabad,India,4-7 Jan,1997,140-144.[10]Sri Parameswaran,M.F.Schulz M.F,Computer-aided selection of components for technology-Independent specifications,IEEE Trans.on Comput-Aided Des.Integr.Circuits Syst.,1994,13(11),1333-1350.[11]P.K.Jha,N.D.Dute,High-level library mapping for arithmetic components,IEEE Trans.on VLSI Syst.,1996,4(2),157-169.[12]馬聰,王作建,劉明業, VHDL高級綜合系統中多層次.多目標工藝映射策略及其實現,計算機學報, 1999,22(9),975-988.
