同步時序電路的增廣Petri網分析
ANALYSIS OF SYNCHRONOUS SEQUENTIAL CIRCUITS BASED ON EXTENDED PETRI NET
-
摘要: 本文應用帶抑制弧的增廣Petri網建立了基本門電路和常用觸發器的Petri網模型;并運用該模型描述了同步時序電路;提出了增廣Petri網的授權矩陣、狀態轉移方程和觸發器次態與變遷授權條件的關系。在此基礎上可對同步時序電路描述和分析,并用實例證明了該方法的有效性。
-
關鍵詞:
- 時序電路; 增廣Petri網; 邏輯分析
Abstract: The models of the basic gates and typical flip-flops for Petri net are constructed by using a kind of extended Petri net with inhibitor arc. Then the syncronous sequential circuit are described. The enabled matrixes, the state equations and the relation between the next state of flip-flop and the enabled transition are given. Based on these, the analysis method of Petri net for synchronous sequential circuits is discussed. It is proved that the theory is effective by practical examples. -
古天龍.系統仿真學報,1994,6(2); 32-36.[2]閻石.數字電子技術基礎.北京:高等教育出版社,1993, 236-302.[3]Peterson J L. Petri Net Theory and the Modeling of System. NJ: Prentice Hall, 1981,第3,4章.[4]Murata T. Proc[J].IEEE.1989, 77(4):541-574 -
