介質鏡象線的阻抗匹配器
THE IMPEDANCE MATCHING ELEMENT OF DIELECTRIC IMAGE LINE
-
摘要: 本文分析了介質鏡象線的波阻抗與幾何尺寸和頻率的關系;研究了阻抗匹配的必要性和可能性;提出了一種選優的匹配器。對于阻抗比為4.7的兩截介質鏡象線,得到駐波系數S1.10的帶寬達10.5 GHz的寬帶特性。選優匹配器的性能優于用經典方法設計的匹配器。
-
關鍵詞:
Abstract: In this paper the wave impedaa.ee of dielectrie image line as a function of geometry dimensions and frequency is analyzed. Both the necessity and the possihility of impedance matching are studied. An optimal matching element is put forward. Its bandwidth with VSWR1.10 can be as wide as10.5 GHz, when it is connected between two dielectrie image lines with an impedance ratio of 4.7. Its properties are obviously better than those of elassical type. -
J. A. Paul and Y. W. Chang, IEEE Trans. on MTT, MTT-26 (1978), 751.[2]北京大學數學系試驗設計組編,正交試驗法,科學普及出版社,1979.[3]R. M. Knox and P. P. Toulios, Integrated circuits for Millimeter-optical Waveguide, Proc. Symp. Submillimeter Wave, N. Y., Edited by Jerome Fox, Mar. 1970, pp. 497-516.[4]史美琪,蔣定華,通信學報,1985年,第2期,第1頁.[5]R. E. Collin and J. Brown, Proc. IEEE Pt. C, 103 (1956), 153.[6]上海科大CAD組,微波階梯阻抗均衡器的最優設計初探,全國電子線路CAD學術討論會文集,1980年10月.[7]陳開周,趙希明等,西北電訊工程學院學報,1982年第2期,第22頁. -
