導電媒質包圍的球形空腔內的圓環天線的特性
THE CHARACTERISTICS OF A CIRCULAR LOOP ANTENNA IN SPHERICAL CAVITY SURROUNDING BY CONDUCTIVE MEDIUM
-
摘要: 本文導出了導電媒質在被其包圍的球形空腔中的圓環天線內產生的輸入阻抗的公式。描述了導電媒質中天線輻射性能的定義。導出了圓環天線的輻射電阻公式。數值計算結果表明所得的兩個公式收斂迅速,一般只需取第一項或前兩項之和即可。探討了這些數值與空腔半徑等參數之間的關系。
-
關鍵詞:
- 圓環天線; 導電媒質; 輸入阻抗; 輻射電阻
Abstract: A formula of input impedance of a circular loop antenna in spherical cavity surrounding by conductive medium is obtained. The definition of radiation performance of the antenna in conductive medium is given. The formula of radiation resistance of the antenna is derived. The results of numerical calculation show that the two formulas converge very fast, so it is feasibe to take the first term or the sum of first two terms only. The relationship between above mentioned characteristics and the parameters, such the radius of spherical cavity and others, is discussed. -
任朗,天線理論基礎,人民郵電出版社,北京,1980, p.500, p.38.[2]W. R. Smythe, Static and Dynamic Electricity,McGraw-Hill Book Company, Inc., 1950, 273-274.[3]《數學手冊》編寫組,數學手冊,人民教育出版社,北京,1979, pp. 627-640. -
