用線性電壓掃描的電容-時間瞬態測定少子產生壽命
DETERMINATION OF GENERATION LIFETIME FROM C-t TRANSIENTS UNDER LINEAR VOLTAGE RAMP BIAS
-
摘要: 本文建議用耗盡的線性掃描電壓掃描MOS電容樣品。掃描開始前MOS電容被置于強反型態,以消除表面產生的影響。根據掃描所得的電容-時間瞬態曲線,可確定樣品中少于產生壽命。實驗表明,對于同一個MOS電容樣品,不同電壓掃描率下得到的結果有很好的一致性,且與飽和電容法的結果相符合。
-
關鍵詞:
- 半導體; MOS電容; 少子產生壽命
Abstract: When a linear voltage ramp applied to the gate of an MOS device the C-t transients are observed. Before the voltage ramp is applied the MOS capacitor is biased into strong inversion in order to eliminate the surface generation. From the C-t transient curve obtained experimentally, the minority carrier generation lifetime in semiconductor can be determined. The experimental results show that for the same sample the lifetimes extracted from the C-t curves obtained under different voltage sweep rates are consistent each other, and they are consistent with the lifetimes extracted fdom saturation capacitance method. -
M. Zerbst,Z.angew. Phys., 22 (1966)l,30-33.[2]R.F.Pierret, IEEE Trans. on ED, ED-19(1972)7,869-873.[3]R.F.Pierret, IEEE Trans. on ED, ED-22(1975)9, 1051-1052.[4]包宗明,蘇九令,物理學報,29(1980)6,693-697.[5]K.S.Rabbani, D.R.Lamb, Solrd-State Etectronics, 24(1981)6,661-664.[6]張秀淼,包宗明,蘇九令,物理學報,32(1983)2,239-246.[7]張秀淼,賀國根,半導體學報,4(1983) 5,444-448.[8]D. K. Schroder, H. C. Nathanson, Solid-Staze Electronics, 13(1970)5, 577-581.[9]D. K. Schroder, J. Guldberg, Solid- State Electronics, 14(1971) 12, 1285-1297.[10]P. U. Calzolari, S.Graffi, C. Morandi, Solid-State Etectronics,17(1974) 10. 1001-1011.[11]K.S.Rabbani, Solid-State Etectronics, 30(1987)6, 607-613.[12]P. G. C. Allman, IEE Proc.-I, 129(1982)4, 121-124.[13]X. Zhang, Solid-State Electronics, 33(1990)9, 1139-1142.[14]C.S.Yue, H. Vyas, M. Holt,J.Borowick, Solid-State Electronics, 28(1985)4, 403-406. -
