月形波導和加片圓波導的解析分析
ANALYSIS OF LUNAR WAVEGUIDES AND VAINED CIRCULAR WAVEGUIDES
-
摘要: 采用模匹配方法分析了月形波導和加片圓波導的截止頻率。波導中的場采用半數階Bessel函數展開并令其滿足邊界條件,從而獲得截止頻率的特征方程國。根據本文所給公式可求解任意尺寸的月形波導、倒月形波導和加片圓波導的截止頻率,并獲得穩定的、具有高精度的解。
-
關鍵詞:
- 月形波導; 截止頻率; 柱諧展開; 加法定理、邊界條件
Abstract: The Lunar waveguides and vained circular waveguides are analyzed by using the mode matching method. The fields in the waveguides are expressed by cylindrical harmonic expansions in which Bessel functions with half orders are involved and the boundary conditions are imposed. Characteristic equations for cutoff wave numbers for both TE and TM modes are obtained. Several waveguides of different relative dimension are calculated, and the results show high accuracy and are considerably steady. -
J. R. kuttler. IEEE Trans.on MTT, MTT-32(1984)4, 348-354.[2]J. A. Roumrliotis et al.,Radio Sci. 15(1980)5, 923-937.[3]Zhang Liyang et al., IEEE Troans. on MTT, MTT-39(1991)8, 1416-1420. -
