3DH系列可調恒流管性能和原理分析
ANALYSIS OF THE CHARACTERISTICS AND PRINCIPLES OF 3DH SERIES ADJUSTABLE CURRENT REGULATOR
-
摘要: 本文分析了一種新型恒流器件的特性和原理,由于采用恒流二極管供流和實現最佳溫度補償獲得了非常穩定的輸出電流。器件的動態阻抗大,電流溫度系數H10-4/℃,恒定電流IH在5--500mA范圍內具有連續可調等優點。
-
關鍵詞:
- 半導體器件; 恒流二極管; 電流溫度系數
Abstract: The characteristics and principles of a new current regulator are analysed- As A result of adopting the current regulator as the current supply and realizing the optirrium temperature compensation, a very stable output current have been obtained. The device not only has large dynamic impedance, current temperature coefficient less than or equal to 10-4/℃. but also has the advantage of continuous adjustability of output current from 1 mA to 500 mA. -
R. J. Widlar, IEEE Trans. on CT, CT-12(1965)12, 586-588.[2]A. B. Grebene, S. K. Ghandhi, Solid-State Electronics, 12(1969)7, 573-58.[3]H. E. Talley, Physical of Semiconductor Devices, Chap.7, The Iowa State University Press,(1976 ).[4]亢寶位,場效應晶體管理論基礎,科學出版社,1985年,第76-81頁. -
