基于FPGA和2位串行分布式算法的實時高速二維DCT/IDCT處理器研制
A REAL-TIME 2-D DCT/IDCT PROCESSOR USING FPGAs
-
摘要: 本文在W.Li(1991)循環斜卷積算法和分布式算法的基礎上,通過軟件模擬和具體硬件設計,利用FPGA完成了可用于高清晰度電視核心解碼器及其它信號與信息處理系統的88二維DCT/IDCT處理器的全部電路設計工作。它采用一根信號線控制計算DCT/IDCT,其輸入、輸出為12位,內部數據線及內部參數均為16位。
-
關鍵詞:
- 現場可編程門陣列; 二維DCT/IDCT處理器; 分布式算法
Abstract: Based on the skew-circular convolution distributed algorithm presented by W.Li(1991). A 88 2-D DCT/IDCT processor has been designed using FPGAs, which can be used for HDTV s decoder or other signal and information processing systems. It can be used to calculate either DCT or IDCT depending on a single control line. AM of the input/output are 12-bit and the internal data bus and internal parameters are 16-bit. -
盧煊.等.基于FPGA的實時高速二維DCT/IDCT處理器.徽電子學.1996,(1): 15-19.[2] Li W. A New Algorithm to Compute the DCT and its Inverse. IEEE Trans.on SP, 1991, SP-39(6): 1305-1313.[2]Xilinx Inc. The Programmable Logic Data Book. 1993.[3]孟憲元可編程專用集成電路原理、設計和應用電子工業出版社, 1995. -
