受主型界面態在深亞微米槽柵PMOSFET中引起退化的研究

任紅霞,  郝躍

任紅霞, 郝躍. 受主型界面態在深亞微米槽柵PMOSFET中引起退化的研究[J]. 電子與信息學報, 2002, 24(1): 108-114.
引用本文: 任紅霞, 郝躍. 受主型界面態在深亞微米槽柵PMOSFET中引起退化的研究[J]. 電子與信息學報, 2002, 24(1): 108-114.
Ren Hongxia, Hao Yue. Study on the degradation induced by acceptor interface state for deep-sub-micron grooved-bate PMOSFET\s[J]. Journal of Electronics & Information Technology, 2002, 24(1): 108-114.
Citation: Ren Hongxia, Hao Yue. Study on the degradation induced by acceptor interface state for deep-sub-micron grooved-bate PMOSFET\s[J]. Journal of Electronics & Information Technology, 2002, 24(1): 108-114.

受主型界面態在深亞微米槽柵PMOSFET中引起退化的研究

Study on the degradation induced by acceptor interface state for deep-sub-micron grooved-bate PMOSFET\s

  • 摘要: 界面態引起的器件特性的退化是深亞微米器件失效的一個重要因素。本文基于流體動力學能量輸運模型,對溝道雜質濃度不同的槽柵和平面PMOSFET中受主型界面態引起的器件特性的退比進行了分析。研究結果表明同樣濃度的界面態密度在槽柵器件中引起的器件特性的漂移遠大于平面器件,且P型受主型界面態密度對器件特性的影響也遠大于N型界面態。溝道雜質濃度不同,界面態引起的器件特性的退化不同。
    Abstract: The degradation induced by interface state is one main reason for failure occurs in deep-sub-micron MOS devices. Based on the hydrodynamics energy transport model, the degradation induced by acceptor interface state is analyzed for deep-sub-micron grooved-gate and conventional planar PMOSFET with different channel doping density. The simulation results show that the degradation induced by the same interface state density in grooved-gate PMOSFET is larger than that in planar PMOSFET and in both structure devices, the impact of P type acceptor interface state on device performance is far larger than that of N type. It also manifests that the degradation is different for the device with different channel doping density.
    • HTML全文
  • C. Hu, Simulating hot-carrier effects on circuit performance, Semiconductor Science Technology,1992, 7(3), B555-B558.[2]J.E. Chung, M. Jeng, J. E. Moon, P. K. Ku, C. Hu, Low-voltage hot-electron currents and degradation in deep-sub-micrometer MOSFETs, IEEE Trans. on Electron Devices, 1990, 37(7),1651-1657.[3]C. Fiegna, H. Iwai, T. Wada, et al., Scaling the MOS transistor below 0.1 m: Methodology,device structures, and technology requirements, IEEE Trans. on Electron Devices, 1994, 41(6),941-949.[4]C. Hu, S. Tam, F. C. Hsu, P. K. Ko, T. Y. Chan, K. W. Terrill, Hot-electron-induced MOSFET degradation-model, monitor and improvement, IEEE Trans. on Electron Devices, 1985, 32(2),375-385.[5]H.I. Kimura, J. Tanaka, H. Noda, Short-channel-effect-suppressed sub-0.1-m grooved-gate MOSFETs with W gate, IEEE Trans. on Electron Devices, 1995, 42(1), 94-99.[6]Paul-Henri Bricout, Emmanuel Dubois, Short-channel effect immunity and current capability of sub-0.1-micron MOSFETs using a recessed channel, IEEE Trans. on Electron Devices, 1996,43(8), 1251-1255.[7]R. Woltjer, G. M. Paulzen, H. G. Pomp, H. Lifka, P. H. Woerlee, Three hot-carrier degradation mechanisms in deep-submicron PMOSFETs, IEEE Trans. on Electron Devices, 1995, 42(1),109-114.[8]Technology Modeling Associates, Inc. Medici Two-Dimensional Device Simulation Program Version 2.3 Users Manual, Vol.1, Feb 1997Technology Modeling Associates, Inc. TSUPREM-4 Two-Dimensional Process Simulation Program Version 6.5 User Manual , May 1997[9]S. Tam, P. Ko, C. Hu, Luck-electron model of channel hot-electron injection in MOSFETs, IEEE Trans. on Electron Devices, 31(9), 1984, 1116-1125.[10]任紅霞,郝躍,許冬崗,槽柵NMOSFET抗熱載流子效應的研究,物理學報,2000,49(7),741-748.
