基于AutoCAD自動建模技術的任意形狀導體電容MoM計算
The MoM Solution for the Capacitance of an Arbitrary Shaped Conducting Body Based on AutoCAD Modeling
-
摘要: 該文首先研究了任意形狀導體的AutoCAD自動建模,得出了基于三角形面片的任意形狀導體表面的模型.接著著重研究了利用矩量法求解任意形狀導體的理論基礎,推導出了任意三角形自作用單元的解析公式以及互作用單元的數值解。最后,給出了一些二維,三維的任意導體的數值結果,并且給出了這些數值結果的Richardson外推值,計算結果與文獻以及精確解都吻合的比較好,從而說明了該方法的有效性和準確性。
-
關鍵詞:
- 任意形狀導體電容; AutoCAD; 矩量法; Richardson外推
Abstract: The auto-modeling of an arbitrary shaped conducting body is studied by the software AutoCAD firstly, and the surface model of the conducting body is achieved on base of many basic triangle meshes. Then the basic theory of the solution for the capacitance of an arbitrary shaped conducting body is presented by method of moment, and the closed-form of diagonal matrix elements and the numerical result of off-diagonal matrix elements are deduced. Finally, some examples of two-dimensional and three-dimensional bodies are given, at the same time the Richardsons extrapolations of these numerical results are calculated. The results agree well with the corresponding close-form and the reference value in literature. Thus the methods accuracy and high efficiency are illuminated. -
Cheng D K, Liang C H. Thinning technique for moment method solutions[J].Proc. IEEE.1983,71(2):265-266[2]Kuo J T, Su Ke-Ying. Analytical evaluation of the MoM matrix elements for the capacitance of a charged plate. IEEE Trans. on Microwave Theory Tech., 2002, MTT-50(5): 1435-1436.[3]Bancroft R. A note on the moment method solution for the capacitance of a conducting flat plate.IEEE Trans. on Antennas Propagat., 1997, AP-45(11): 1704-1705.[4]Harrington R F. Field Computation by Moment Methods. New York: Macmillan, 1968: 29-34.[5]金建銘(美),王建國譯,葛德彪校.電磁場有限元方法.西安:西安電子科技大學出版社,1998.2:92-93.[6]呂濤,石濟民,林振寶.分裂外推與組合技巧.北京:科學出版社,1998:1-8.[7]蔡耀志.數值逼近.杭州:浙江大學出版社,1991:94-96.[8]虞福春,鄭春開.電動力學.北京:北京大學出版社,1992:31-32.[9]Nabors K, Kim S, White J. Fast capacitance extraction of general three-dimensional structures.IEEE Trans. on Microwave Theory Tech., 1992, MTT-40(7): 1496-1506.[10]Ruehli A E, Brennan P A. Efficient capacitance calculations for three-dimensional multi-conductor systems. IEEE Trans. on Microwave Theory Tech., 1973, MTT-21(2): 76-82.[11]Mascagni M. First and last passage random walk algorithms. Mathematics and Computational Sciences Divisions Seminar Series in Gaithersburg, MD, Dec. 2001: 1-36. -
