慢波組件的焊接工藝
A WELDING TECHNOLOGY FOR SLOW WAVE STRUCTURE
-
摘要: 正 慢波組件的散熱能力是螺旋線行波管向高頻、大功率、寬頻帶發展的主要障礙之一。本文就此問題提出了一種能獲得散熱能力高、高頻損耗小的、簡單可靠的工藝方法。還提出了散熱能力的測量方法,并給出了測量結果。 (一)焊接工藝 1.慢波組件裝配 試驗慢波組件的尺寸如圖1所示。首先將螺旋線鍍上2025m厚的銅層。然后用真空蒸涂的方法在瓷桿上蒸涂一條鈦層,并再在Ti層上蒸涂一層Ag-Cu合金
-
關鍵詞:
Abstract: The capability of heat conduction of the slow wave structure is one of the main obstaeles to the development of the high-frequency high-power helix TWTs. A simple but reliable technological method for obtaining high heat conduction capability and low rf loss is suggested. The method of measurement of the heat conduction capability and the results of this measurement are given also. -
