摘要:
本文敘述了一個具有高準確度的對數函數和通帶較寬的對數放大器。該放大器用RC充放電的指數函數和脈寬調制的方法,提高了對數函數的準確度,從而可以解決天文、宇航、精確測量和通信等方面的很多關鍵問題。 根據RC充放電電壓與時間的指數關系,再將時間用脈沖調制轉換成電壓,就構成了輸入輸出的對數關系。使用取樣定理、香農基礎信道容量公式和多級放大帶寬公式等,對該系統進行了理論分析。搭試了一個具體電路,取得了系統特性數據,證實了該系統的對數函數準確度可達99％以上。
Abstract:
A high precision logarithmic amplifier with wide passband is achieved by using the charge and discharge of RC and the method of pulse-width modulation. It can be used in the astronomy, astronavigation, accurate measurement, communication etc. The theoretical analysis of the circuit is given. A practical circuit is constructed, and the experimental result shows that the logarithmic function for the circuit reaches 99% of the theoretical value.
