磁體工作狀態判斷標準的改進
AN IMPROVED CRITERION TO JUDGE THE ENERGY CONTRIBUTION OF MAGNETS
-
摘要: 磁體結構優化設計需要用最少量的磁體產生最強的磁場,其要點之一是保證磁體的每一部分工作在退磁曲線上盡量靠近最大磁能積(BH)max的地方,目前用于磁場計算的程序CTA對磁體工作點的算法有缺陷,它對一個形狀復雜磁體結構的磁場能量貢獻大小的計算也不能給出唯一的結果,以便當作設計優劣的判據。作者就程序算法進行改進后,對每個磁體結構給出一個統一的平均磁能積作為判斷磁體工作狀態的標準,并進一步畫出了磁能積的分布圖。
-
關鍵詞:
- 磁體工作點; 平均磁能積; 磁能積分布
Abstract: The optimum design of magnet structures requires that every part of the magnets work at a point on the demagnetization curve which is as near to (BH)max as possible. CTA is a program for the computation of magnetic fields in axisymmetric systems. It has some defects in its search for magnet working points, and furthermore, for a complex structure it cannot provide a sole result to judge how much magnetic energy is contributed by the magnets. In this paper the authors introduce average magnetic energy product to serve as a criterion for the judgment of the work state of magnets. For every magnet structure the improved CTA can present a unique average magnetic energy product and a map of the energy product distribution. -
J.H. Jensen, Optimization method for permanent-magnet structures, IEEE Trans. on Magnetics,1999, 35(6), 4465-4472.[2]J.H. Jensen, M. G. Abele, Maxinally efficient permanent magnet structures, J. Appl. Phys.,1996, 79(2), 1157-1163.[3]K.R. Davey, Magnet design optimization using variable metrics, IEEE Trans. on Magnetics,1995, 31(6), 3566-3568.[4]F. Bloch, O. Cugat, Innovating approaches to the generation of intense magnetic fields: design and optimization of a 4 Tesla permanent magnet flux source, IEEE Trans. on Magnetics, 1998,34(5), 2465-2468.[5]Xie Dexin, et al., Shape design optimization in non-linear magnetic problems using simulated annealing with complex strategy, IEEE Trans. on Magnetics, 1995, 31(6), 3569-3571.[6]Wu Xunlei, et al., Calculation of nonlinear magnetic fields in cylindrically symmetric system.[7]周壽增,董清飛著,超強永磁體,北京,冶金工業出版社,1999年,63-68. -
