中頻脈中壓縮信號數字化直接產生技術研究
On direct digital generation of IF pulse compression signals
-
摘要: 該文提出了一種脈沖壓縮中頻信號數字化產生方法及硬件實現方案,對其中的一些關鍵問題做出了定量分析;在此基礎上完成了一套波形產生器,可產生6種中頻15MHz、帶寬1MHz、時寬等于或小于300s的線性調頻、非線性調頻信號。測試表明其諧波與雜散均優于-68dB,完全達到工程應用要求。Abstract: In this paper, a method of direct digital generation of intermediate frequency(IF) pulse compression signals is proposed, and the hardware architecture is also presented. Some key issues are analyzed quantitatively. Based on these, a generation system is implemented, which is applicable to generate six kinds of LFM, NLFM waveforms. The designed IF reaches 15MHz and bandwidth reaches 1MHz with timewidth equal to or less than 300s. The measuring results of SFDR and noise are all below-68dB, which show that the performances of the system can meet the needs of practical engineering application.
-
H.D. Griffiths, W. J. Bradford, Digital generation of high time-bandwidth product linear FM waveforms for radar alt imeters, IEE Proc.-F, 1992, 139(2), 160-169.[2]S.P. Caldwell, M. M. Driscoll, W. S. Foley, J. T. Haynes, T. D. Merrell, Recent advances in exciter and waveform generator technology, IEEE NRC, 1993, 40-45.[3]蔡英杰,向敬成,寬帶LFM/NLFM信號及其產生,系統工程與電子技術,1999(21),36-40. ［4］張厥盛,曹麗娜,鎖相與頻率合成技術,成都,電子科技大學出版社,1995,140-160.[4]林茂庸,柯有安,雷達信號理論,北京,國防工業出版社,1984,第五、六、九章. -
