寬帶速調管輸出段的時間積分程序
THE TIME INTEGRAL PROGRAM FOR OUTPUT SECTION OF BROADBAND KLYSTRONS
-
摘要: 本文采用一維單周期時間積分模型計算速調管輸出段的電子與高頻場的能量交換過程,比較簡單地解決了距離積分向時間積分的過渡以及輸出段中電子圓盤間空間電荷力的計算問題。用DJS-6自動化語言編寫了計算程序,用該程序計算了C波段寬帶速調管,計算結果與實測值基本一致。利用該程序?qū)敵龆蔚闹匾獏?shù)如阻抗、間隙渡越角等對效率的影響作了研究。
-
關鍵詞:
Abstract: In this paper, we present a single period, one dimensional time integral model, with which we can calculate the energy exchange between the rf field and electrons in the output section of a klystron. We give a method by which the distance integral can be transformed simply into the time integral and the calculation of the space charge force of electron disks in the output section can be resolved.We write a program with DJS-6 type computer automation language, with which we calculate a C-band broadband klystron. It shows that the calculated resultsand the experimental ones are in good agreement. We also study the influence of the parameters of output section on the efficiency of the klystron. -
S. E. Webber, IRE Trans. on ED, ED-5(1958), 206.[2]P. J. Tallerico, IEEE Trans. on ED, ED-18 (1971), 374.[3]J. R. Hechtal, IEEE Trans. on ED, ED-16(1969), 212.[4]電子管設計手冊編輯委員會編,大功率速調管設計手冊,第二章,國防工業出版社,1979年.[5]J. R. Rowe, Nonlinear Electron-Wave Interaction Phenomena. Academic Press, N. Y. 1965. Chapter V.[6]T.K.Yama et al., IEEE Trans. on ED, ED-24(1977), 3. -
